Vidit Aluminium is a well-respected manufacturer and supplier of Aluminium 5754 Flat Bars based in Dubai, UAE. They’ve built a solid reputation for providing high-quality products that adhere to international standards. These Aluminium 5754 Flat Bars are highly valued for their outstanding corrosion resistance, impressive strength, and excellent formability, making them perfect for tough industrial and commercial uses. Vidit Aluminium is committed to precision manufacturing, durability, and dependable performance, serving various sectors like marine, construction, automotive, and engineering. With a strong emphasis on customer satisfaction, the company offers tailored solutions and ensures timely delivery throughout the UAE and beyond.
Aluminium 5754 Flat Bars are primarily made of aluminium, with magnesium as the key alloying element, which boosts their corrosion resistance and mechanical strength. They also include trace amounts of manganese, iron, silicon, and chromium, all of which enhance their durability. In terms of mechanics, Aluminium 5754 boasts a good tensile strength ranging from about 220 to 300 MPa and excellent fatigue resistance. These bars are also known for their high weldability, good workability, and resistance to seawater and industrial pollutants. Their balanced strength-to-weight ratio makes them ideal for lightweight yet sturdy structural applications.
Standards : ASTM B221, B211, B565, B316, AMS 4121 5754
Temper :O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H32,H34,H36,H38,H111,H112,H114,H 116,H321
Standard : ASTM, ASME, AMS, GB/T, JIS
Length : 100 mm To 3000 mm Long & Above, Random, Fix & Cut Length or as per clients’ requirement
Size : 5 mm To 500 mm
Finish : Bright, Polish & Black
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Sheet
| Alloy | Mg | Mn | Si | Cu | Fe | Cr | Zn | Ti | Cu | Other | AI | |||||||||||
| 5754 | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | balance | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2.60 | 3.60 | 0.0 | 0.50 | 0.0 | 0.40 | 0.0 | 0.40 | 0.0 | 0.30 | 0.0 | 0.20 | 0.0 | 0.15 | 0.0 | 0.10 | 0.0 | 0.05 | 0.0 | 0.15 | |||
| Alloy | Temper | Thermal conductivity | Coefficient of thermal expansion | Melting point | Elastic modulus | Electrical conductivity | |
|---|---|---|---|---|---|---|---|
| W/m*K | µm/(m*K) | Min | Max | KN/mm2 | %IACS | ||
| 5754 | H22 | 132 | 23,7 | 595 | 645 | 70 | 32,5 |
| 132 | 23,7 | 595 | 645 | 70 | 32,5 | ||
| 132 | 23,7 | 595 | 645 | 70 | 32,5 | ||
| 132 | 23,7 | 595 | 645 | 70 | 32,5 | ||
| 23,7 | 595 | 645 | 70 | ||||
| 132 | 23,7 | 595 | 645 | 70 | 32,5 | ||
| European Standard | GERMANY | UNS | WERKSTOFF NR. |
| AW-AlMg2.5 | Al-Mg.2 | A95754 | 3.3535 |
Vidit Aluminium based in Dubai, UAE is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 5754 Flat Bars to meet specific project needs. Our team at Vidit Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@viditaluminium.ae
These Aluminium 5754 Flat Bars find extensive use in industries that demand strength, corrosion resistance, and lightweight characteristics. In the marine industry, they’re utilized for shipbuilding, flooring, and offshore structures due to their excellent resistance to seawater. In construction, they’re applied in architectural frameworks, bridges, and various building components. The automotive sector uses them for body panels, chassis parts, and interior structures. They’re also popular in the chemical and food processing industries, thanks to their corrosion resistance and hygienic properties. Additionally, they play a role in transportation, pressure vessels, pipelines, and general engineering applications.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
