Vidit Aluminium is a well-respected manufacturer and supplier of Aluminium 5754 Circles based in Dubai, UAE. They pride themselves on delivering top-notch products that adhere to international standards. These Aluminium 5754 Circles are renowned for their impressive corrosion resistance, durability, and exceptional surface finish, making them a go-to choice across various industries. This particular alloy is celebrated for its remarkable formability, machinability, and weldability, which makes it a versatile option for both heavy-duty and decorative uses. Vidit Aluminium guarantees precision engineering and dependable performance, providing Aluminium 5754 Circles that are perfect for marine, automotive, construction, and industrial sectors where strength, lightweight properties, and longevity are crucial.
Aluminium 5754 Circles are primarily made of aluminium, with magnesium as the key alloying element, giving them excellent resistance to seawater and industrial pollutants. As a non-heat-treatable alloy, they maintain good mechanical strength, with tensile strength ranging from 220 to 330 MPa and yield strength between 80 and 240 MPa. The Brinell hardness is approximately 65 HB, ensuring they are both durable and tough. Additionally, they boast outstanding weldability, machinability, and formability, making fabrication a breeze. Their lightweight yet robust nature makes Aluminium 5754 Circles ideal for demanding environments and long-lasting structural or functional applications.
| Specifications | ASTM B209 / ASME SB209 |
|---|---|
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 1 Mm To 100 mm |
| Diameter | Upto 2000 mm |
| Circle Diameter | 3″ DIA up to 38″ DIA 1500 lbs max |
| Circles Form | Hot Rolled Circles, Cold Rolled Circle, Proof Machined Circles |
| Finish | Mill, Customer specific finish |
| Aluminum Circle Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Mg | Mn | Si | Cu | Fe | Cr | Zn | Ti | Cu | Other (Each) | Others (Total) | Al |
| 2.60 – 3.60 | 0.0 – 0.50 | 0.0 – 0.40 | 0.0 – 0.40 | 0.0 – 0.30 | 0.0 – 0.20 | 0.0 – 0.15 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.05 | 0.0 – 0.15 | Balance |
| Proof Stress | Tensile Strength | Elongation at 50 mm | Hardness Brinell |
| 80 Min MPa | 190 – 260MPa | 12 Min % | 52 HB |
| UNS | EN | DIN | ISO | USA | WNR |
| A95754 | EN AW-5754 | AlMg3 | AlMg3 | AA5754 | 3.3535 |
Vidit Aluminium based in Dubai, UAE is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 5754 Circles to meet specific project needs. Our team at Vidit Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@viditaluminium.ae
Aluminium 5754 Circles are incredibly popular in various industries that need materials that are strong, lightweight, and resistant to corrosion. In the marine industry, for instance, they’re perfect for shipbuilding, decks, and offshore structures because they stand up so well to seawater. The automotive sector also makes good use of them for body panels, wheel components, and fuel tanks. In construction, you’ll find them in roofing, cladding, stair treads, and architectural panels. They’re also used in industrial settings for tanks, machinery, cookware, and packaging. Thanks to their excellent formability, they’re ideal for deep drawing and spinning processes. With their outstanding durability and ease of fabrication, Aluminium 5754 Circles have become a go-to choice in engineering and manufacturing.
