Vidit Aluminium stands out as a top-notch manufacturer and supplier based in Dubai, UAE, specializing in high-quality Aluminium 5754 Bars that cater to a variety of industrial and structural needs. These bars are celebrated for their remarkable corrosion resistance, impressive strength, and excellent machinability, making them a go-to choice in industries like marine, automotive, aerospace, construction, and engineering. Vidit Aluminium prides itself on utilizing advanced production techniques and maintaining rigorous quality control, ensuring that their Aluminium 5754 Bars deliver durability, precision, and long-lasting performance. With a range of sizes, lengths, and finishes available, these bars are customized to meet the specific requirements of clients, earning their reputation as a reliable option in both the UAE and global markets.
Aluminium 5754 Bars are primarily made up of aluminium and magnesium, along with small amounts of manganese, iron, silicon, and chromium. This unique blend gives them exceptional corrosion resistance, particularly against seawater and various chemicals, while also enhancing their strength and machinability. On a mechanical level, these bars showcase good tensile strength, high yield strength, and impressive elongation properties. Their lightweight design, excellent weldability, and resilience in tough environments make them ideal for heavy-duty and long-term applications across a range of industries.
| Bar Wire Standard | ASTM B221, B211, B565, B316, AMS 4118 5052 |
| Bar Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Bars Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Bar Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Tempers | Tempers range from dead soft annealed to ultra spring temper |
| Rolled Flat Bars Condition | Hardened & tempered, annealed |
| Cold Rolled Bar Technique | Aluminium Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Rounds Bar Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Grade | Fe | Si | Mg | Mn | Cu | Zn | Cr | Ti |
| Aluminium 5754 | 0.0 – 0.30 | 0.0 – 0.40 | 2.60 – 3.60 | 0.0 – 0.50 | 0.0 – 0.05 | 0.0 – 0.15 | 0.0 – 0.20 | 0.0 – 0.10 |
| Grade | Tensile Strength | Hardness | Elongation % |
| Aluminium 5754 | 190 – 260Mpa | 52 HB | 12 Min % |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 5754 | A95754 | 3.3535 |
Vidit Aluminium based in Dubai, UAE is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 5754 Bars to meet specific project needs. Our team at Vidit Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@viditaluminium.ae
These Aluminium 5754 Bars find extensive use in sectors where strength, corrosion resistance, and reliability are crucial. In the marine industry, they are commonly used in shipbuilding, boat hulls, and offshore structures due to their outstanding resistance to seawater. The automotive sector incorporates them into body panels, chassis, and structural components that require strength without adding unnecessary weight. In construction, these bars are essential for frameworks, bridges, and various architectural applications. Moreover, Aluminium 5754 Bars are widely utilized in pipelines, transport systems, chemical processing, and general engineering projects, providing cost-effective, durable, and high-performance solutions for a diverse array of applications.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
