Introducing Vidit Aluminium, a top-notch manufacturer and supplier of Aluminium 1050 Square Bars right here in Dubai, UAE. We take pride in delivering high-quality products that are built for reliability and performance. Our bars meet international standards and are celebrated for their impressive corrosion resistance, excellent ductility, and remarkable thermal conductivity. Lightweight yet incredibly durable, these Aluminium 1050 Square Bars are perfect for a variety of industrial and commercial uses. At Vidit Aluminium, we focus on precision in production, timely deliveries, and competitive pricing, making us a trusted partner for aluminium solutions in the UAE and beyond, serving sectors like construction, electrical, and chemical processing.
Aluminium 1050 Square Bars are made up of 99.5% pure aluminium, with small amounts of elements such as silicon, iron, copper, manganese, and zinc. They boast a tensile strength ranging from 60 to 100 MPa, excellent elongation, and a low density of 2.71 g/cm³, which means they’re lightweight yet strong and easy to machine. These bars also provide high thermal conductivity (around 222 W/mK) and good electrical conductivity, making them perfect for heat and power applications. While they may not be as strong as some alloyed aluminium grades, their exceptional corrosion resistance, formability, and polishability make them incredibly versatile for various fabrication and industrial needs.
Specification : ASTM B 221 ASME SB 221, B211, B565, B316 1100, AMS 4102
Standard : ASTM, BS and all International Standards
Temper : O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Length : 100 mm To 3000 mm Long & Above
Size : 5 mm To 500 mm
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
Vidit Aluminium based in Dubai, UAE is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminum 1050 Square Bars to meet specific project needs. Our team at Vidit Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@viditaluminium.ae
Aluminium UNS A91050 Square Bars are used in a wide range of applications due to their excellent corrosion resistance, high thermal and electrical conductivity, and ease of fabrication. Common uses include architectural elements, signage, heat exchangers, electrical busbars, chemical equipment, and pressure vessels. They are also utilized in the manufacturing of decorative items, railings, and support structures in construction. The material’s versatility and durability make it suitable for both indoor and outdoor applications.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
